Binocular Helmet Night Vision Goggles

JV-NVB204 is a compact and lightweight binocular night vision goggle with a detachable head strap. It adopts a high-performance generation 2+ image intensifier (can also be equipped with a generation 3 image intensifier), which has the advantages of compact size, lightweight, large field of view, clear and distortion-free image, no distortion, etc.

Contact Now E-Mail Telephone WhatsApp

Product Details

Feature

➢ Versatile: it can be used hand-held, and can also be used for headwear and helmet installation

➢ It can be equipped with a single infrared enhancer to enhance the night time effect and extend the scope of application

➢ The built-in infrared indicator and low power indicator (displayed in the eyepiece) enhance the user's concealment

JV-NVB204

Technical parameter

Parameters / Model	JV-NVB204
IIT	GEN2+
Resolution (lp/mm)	60-64
photocathode type	S25
Luminous sensitivity	700-1000
MTTF hours	10000
magnification	1
FOV deg	40
Diopter (deg)	+5/-5
Lens system	F1.2, 25mm
Range of focus(m)	0.25m to infinity
Dimensions(mm)	112 x 108 x 65
Weight(kg)	0.625
Power supply(v)	2.6-4.2
Storage temp	-51 to +85
Environmental rating	IP65/ IP67
Battery type(v)	1 X CR123A lithium battery / 1 XAA battery
Battery life(hrs)	60 – 100 h
Operating temperature(°C)	-51 to +49
Storage temperature(°C)	-51 to +85
